Bobcat™ 230 (Kohler)
Reliable multiprocess engine-driven welder primarily used for Stick welding and creating power. Cost-effective engine-driven welder designed for maintenance and repair operations, construction, field fabrication, farm/ranch and work trucks.
Features
- Easy to Use - Single knob adjustment for quick and precise setup.
- Separate weld and auxiliary power - Full auxiliary power at any setting.
- Exceptional Arc Performance - Easy arc starts and less spatter.
- Easier mobility and uses less truck space and payload - Over 100 pounds lighter and 13 percent smaller than previous models.
- Easy Maintenance - With its intuitive design, the daily maintenance of our Bobcat engine-driven welder is fast and easy.
PROCESSES
- Flux Cored (FCAW)
- MIG (GMAW)
- Stick (SMAW)
| Title | Bobcat™ 230 (Kohler) |
| Industries Interests | Farm and Ranch Work Truck Construction and Fabrication |
| Amperage | 20 Amps - 230 Amps |
| Weldable Metals | Stainless Steel Steel |
| Current Type | DC |
| Portability | Lift Eye (Standard) Running Gear / Cart (Optional) Trailer (Optional) |
| Engine Brand | Kohler |
| Engine Idle Speed | 2300 RPM |
| Engine Weld Speed | 3600 |
| Fuel Tank Size | 11 Gallon |
| Fuel Type | Gasoline |
| Horsepower | 23.5 hp |
| Weld Output | CC / CV |
| Rated Output | CC/DC Stick 230 Amps at 29.2 V, 100% duty cycle, CV/DC MIG/FCAW 230 Amps at 25.5 V, 100% duty cycle |
| Single Phase Auxiliary Continuous Power | 9500 W |
| Single Phase Auxiliary Peak Power | 11000 W |
| Sound Rating | 64 dB @ idle and 73 dB @ weld |
| Applications | Fabrication Industrial Welding Mobile Fabrication & MRO |
| Net Width | 20.13 in |
| Net Height | 26.5 in |
| Net Length | 37.06 in |
| Net Weight | 376 lbs |
| Warranty | 3 Years |
| Accessories | Welding Cable: 219.09.00115 TechniWeld ArcStar Electrode Holder: 219.09.00005 TechniWeld ArcStar Ground Clamp: 219.09.00042 TechniWeld Connector Terminal: 219.09.00153 TechniWeld ArcStar Cable Connector: 219.09.00185 Signature Series Synthetic Motor Oil: 219.17.0003 |
Bobcat™ 230 (Kohler)
Reliable multiprocess engine-driven welder primarily used for Stick welding and creating power. Cost-effective engine-driven welder designed for maintenance and repair operations, construction, field fabrication, farm/ranch and work trucks.
Features
- Easy to Use - Single knob adjustment for quick and precise setup.
- Separate weld and auxiliary power - Full auxiliary power at any setting.
- Exceptional Arc Performance - Easy arc starts and less spatter.
- Easier mobility and uses less truck space and payload - Over 100 pounds lighter and 13 percent smaller than previous models.
- Easy Maintenance - With its intuitive design, the daily maintenance of our Bobcat engine-driven welder is fast and easy.
PROCESSES
- Flux Cored (FCAW)
- MIG (GMAW)
- Stick (SMAW)
| Title | Bobcat™ 230 (Kohler) |
| Industries Interests | Farm and Ranch Work Truck Construction and Fabrication |
| Amperage | 20 Amps - 230 Amps |
| Weldable Metals | Stainless Steel Steel |
| Current Type | DC |
| Portability | Lift Eye (Standard) Running Gear / Cart (Optional) Trailer (Optional) |
| Engine Brand | Kohler |
| Engine Idle Speed | 2300 RPM |
| Engine Weld Speed | 3600 |
| Fuel Tank Size | 11 Gallon |
| Fuel Type | Gasoline |
| Horsepower | 23.5 hp |
| Weld Output | CC / CV |
| Rated Output | CC/DC Stick 230 Amps at 29.2 V, 100% duty cycle, CV/DC MIG/FCAW 230 Amps at 25.5 V, 100% duty cycle |
| Single Phase Auxiliary Continuous Power | 9500 W |
| Single Phase Auxiliary Peak Power | 11000 W |
| Sound Rating | 64 dB @ idle and 73 dB @ weld |
| Applications | Fabrication Industrial Welding Mobile Fabrication & MRO |
| Net Width | 20.13 in |
| Net Height | 26.5 in |
| Net Length | 37.06 in |
| Net Weight | 376 lbs |
| Warranty | 3 Years |
| Accessories | Welding Cable: 219.09.00115 TechniWeld ArcStar Electrode Holder: 219.09.00005 TechniWeld ArcStar Ground Clamp: 219.09.00042 TechniWeld Connector Terminal: 219.09.00153 TechniWeld ArcStar Cable Connector: 219.09.00185 Signature Series Synthetic Motor Oil: 219.17.0003 |
